ZTSJG Fixed scissors lift

Home > PRODUCTS > Vertical elevator > ZTSJG Fixed scissors lift

ZTSJG fixed hydraulic scissor lift platform electric stationa

ZTSJG stationary scissor lift is the special hydraulic lift used for conveying cargos between building layers. The product is mainly used for conveying cargos up and down between workshops warehouse and various working layers: lifting auto-mobiles between layers in stereo garage and understand garage. Product’ hydraulic system has anti-falling and over-loading safety productive devices and all layers and lift working face can set operating buttons to realize multi-point control.
Lift height: 1m-10m;
Load capacity: 100kg-10t
Platform size: customized

PRODUCT DETAIL

ZTSJG stationary scissor lift is the special hydraulic lift used for conveying cargos between building layers. The product is mainly used for conveying cargos up and down between workshops, warehouse and various working layers: lifting auto-mobiles between layers in stereo garage and understand garage. Product’ hydraulic system has anti-falling and over-loading safety productive devices, and all layers and lift working face can set operating buttons to realize multi-point control.

Technical parameters:

Model	Lifting height (m)	Lowered height (mm)	Load capacity (kg)	Table size (m)	power (kw)	Rising time (s)
SJG 0.5-4.5	4.5	750	500	2*1	2.2	77
SJG 1.0-4.5	4.5	850	1000	2*1.5	3.0	80
SJG 2.0-4.5	4.5	900	2000	2.2*1.5	2.2	90
SJG 1.0-7.5	7.5	990	1000	2.2*1.8	3.0	100
SJG 2.0-7.5	7.5	1065	2000	2.4*2.4	4.0	105
SJG 2.0-1.8	1.8	700	2000	2.5*2	3.0	50
SJG 5.0-1.8	1.8	960	5000	3.5*2.5	4.0	88
Lift height & Bearing capacity & Table size all can be customized.
